Blaze Laser
Blaze with LightWELD® laser welding and optional cleaning
-
Designed and built in the USA with direct factory support
-
7-axis positioning allows more welds without refixturing
-
Welds dissimilar materials of different thicknesses
-
Aesthetic high strength joints with minimal or no wire
-
Software: Zero programming, unlimited weld capability
-
Reach: 61" or 85" including laser
Game changer for business
Blaze Laser with LightWeld® opens the door to welding a wider range of materials and thicknesses with minimal distortion, deformation, undercut or burn-through.
Blaze Laser can easily be setup and running parts on day one, without the need for third party integrators, to start automating with the benefits of laser welding and cleaning.
Superpower tool for welders
Automate repetitive welds
New welders can be trained within hours and experienced welders realize an immediate increase to productivity
Double productivity—at a minimum
Choose presets or user defined modes for simple material preparation and minimal post-finishing, plus wobble welding and wire feed options
Strengthen teams & empower welders
High-speed welding with low heat input for minimal part distortion, improved visual appearance and increased overall part quality
Blaze Laser specifications
Teaching: Zero programming
Motion: 7-Axis torch positioning
Weld Library: Unlimited
Repeatability: +/- 0.1 mm (.004”)
IP Class: IP 61
Cobot Safety: Speed & force limited
Laser versus
traditional welding
Laser welding utilizes a highly concentrated laser beam to create precise, deep welds with minimal heat-affected zones, making it ideal for thin materials and intricate designs.
Consider laser welding for high-speed processing, reduced distortion, high precision, efficiency, and reduced post-processing requirements.
Laser weld thick, thin & reflective materials
Stainless Steel
Galvanized Steel
Mild Steel
Aluminum 3 & 5 Series
Aluminum 6 Series
Nickel Alloys
Titanium
Copper
Weld Seam Width
Pre & Post-Weld Cleaning
up to 0.315"
up to 0.315"
up to 0.315"
up to 0.315"
up to 0.200"
up to 0.275"
up to 0.275"
up to 0.120"
up to 5 mm
up to 15 mm
Single system welding & cleaning
Blaze with LightWELD XC and LightWELD XR can switch from welding to cleaning in just seconds. The specially designed welding and cleaning nozzle tips provide for any joint configuration. Using a single system for multiple fabrication processes is a highly efficient productivity booster.
PRE-Weld
cleaning automation
Blaze with optional LightWELD XC or LightWELD XR provides pre-weld cleaning for fast and effective removal of contaminants such as oxides, rust, paint, oil, or grease from the surface without the use of chemicals or abrasives that can compromise weld integrity. Pulsed cleaning power up to 2500 W peak power evaporates undesired surface elements.
Photo credit: IPG Photonics®
POST-Weld
cleaning automation
Optional LightWELD XC and LightWELD XR also provide post-weld cleaning to remove soot, debris, or any sign of localized heating. Create visually appealing welds while eliminating need for post-grinding and dramatically reducing time, cost and scrap. Up to 15 mm of adjustable cleaning width in one pass.
Photo credit: IPG Photonics®
Customer spotlight video: Laser welding replaces 1,000 spot welds to speed up commercial oven production
Drag & drop tablet
The unlimited library of welding recipes allows complete control and customization of all welding parameters.
7-axis positioning
The only welding cobot with 7 joints (others have 6) for more welds without re-fixturing and total maneuvering freedom.
Teach-by-touch
No programming ever needed—you can teach Blaze a job faster than welding it once by hand.
Included with all Blaze collaborative robots
Sealed control computer
Fully integrated electronics. Sealed cabinet protects all electronics from metal dust and gunk.
Specifications
IP Rating: IP61
Communications Hardware: Ethernet 100MB
Protocols: Ethernet IP, TCP/IP, Modbus
Power: 100-240 VAC 50-60 HZ
USA direct factory support
Fast online support by our welding and robotics experts at our US factory. We speak your language.
Zero programming tablet
Using visual ‘tiles’ and a drag & drop interface, Blaze’s control tablet is incredibly intuitive to use.
Specifications
IP Rating: IP41
Connection: USB
Dimensions: 253 mm x 125 mm x 37 mm (10” x 5” x 1.5”)
Cable: 5 meters (16 ft)
Updates, info & resources
Access a comprehensive library of documentation, including product manuals, user guides, video tutorials and software downloads.
Automate with confidence. It's easy to get started.
Request a quote
Questions or unique requirements? We'll respond quickly and are always ready to talk, offer ideas and discuss solutions. Many shops find it helpful to see our cobot capabilities and unmatched ease of operation in an online demo.
Challenge us! Our cobots can easily automate almost any task—and anyone can use them.
